15,000L Devan Tank

15,000L Devan Tank

Enquiry
SKU: TT15S Category:

Description

Call for discounted pricing.

15,000 litres (3,300 gallons)

North Island Model: Width: 3.5 metres Height: 2.0 metres Outlet(s): 2 x 50mm (2 inch) brass BSPT fittings
South Island Model: Width: 2.9 metres Height: 2.6 metres Outlet(s): 2 x 50mm (2 inch) brass BSPT fittings

  • Full 20 Year Warranty (not a pro-rata)
  • Bury up to 500mm deep with clean backfill.
  • Super tough dome – with space frame substructure
  • 11 colours Click on specification or download for more information

Please note that the colours represented are the best match possible within screen and print variations. As colours may vary, please contact us direct if you require a free colour swatch sample.

Get a price and delivery quote by contacting your local tank guy.

All tanks are manufactured to industry best practice with materials that meet:

  • AS/NZS 4020: 2002 Potable (Drinking) Water Standard
  • AS/NZS 2070: Part 1 and Part 8 Australian Standards for Food Contact

Every tank also comes with a 10 Year Warranty

Additional information

Empty weight

North Island: 250kg
South Island: 275kg

Specific gravity

max1.0

Max working temperature

30ºC

Raw material type

Medium density polyethylene

Food contact requirements

AS/NZS 2070 – Raw material standards
AS/NZS4020:2005 – Potable drinking water
AS/NZS4766 – Polyethylene storage tanks for water

Complying water tank standard

AS/NZS4766 Polyethylene storage tanks for water

Manhole opening size

435mm (located at 6 o’clock)

Dimensions: North Island

Width: 3.5m
Overall height: 2.0m
Overflow height: 1.6m
Height to dome part line: 1.4m
Outlet to base centre line: 110mm
Max molded outlets: 3
Outlet locations: standard 1 & 7 o’clock
Other locations – non-standard: 5 o’clock

Dimensions: South Island

Width: 2.9m
Overall height: 2.6m
Overflow height: 2.2m
Height to dome part line: 2.1m
Outlet to base centre line: 120mm
Max molded outlets: 4
Outlet locations – standard: 1 & 7 o’clock
Other locations – non-standard: 5 o’clock & 11 o’clock

Overflow panels

4 off (1, 5, 7 & 11 o’clock)

Outlet size

50mm BSPT 2 off

Lifting eyes

(1, 5, 7 & 11 o’clock)
